名称：45x45x10MM散热风扇
微信：13312956352
手机：13312956352
座机：0755-28058598
在线咨询：
产品详情
| c | |||||||||||
| MODEL |
Rated Voltage |
Operating Voltage Range |
Input Current |
Input Power |
Speed |
Maximum Air Flow |
Maximum Air Pressure |
Noise | |||
| PART NO. | FUNCTION | VDC | VDC | Amp | Watt | R.P.M. | m3 /min | CFM | mmH2O | IN H2O | dB-A |
| AFB04505LA | -R00 / -F00 | 5 | 4.0 to 5.5 | 0.14 | 0.70 | 4000 | 0.218 | 7.70 | 2.05 | 0.081 | 24.5 |
| AFB04512LA | -R00 / -F00 | 12 | 9.0 to 13.8 | 0.08 | 0.96 | 4000 | 0.218 | 7.70 | 2.05 | 0.081 | 24.5 |
| AFB04505MA | -R00 / -F00 | 5 | 4.0 to 5.5 | 0.20 | 1.00 | 5000 | 0.279 | 9.85 | 3.22 | 0.127 | 30.0 |
| AFB04512MA | -R00 / -F00 | 12 | 7.0 to 13.8 | 0.11 | 1.32 | 5000 | 0.279 | 9.85 | 3.22 | 0.127 | 30.0 |
| AFB04512HA | -R00 / -F00 | 12 | 7.0 to 13.8 | 0.17 | 2.04 | 6000 | 0.334 | 11.80 | 4.67 | 0.184 | 34.5 |
